Thin Film Chip Resistors

Product Overview

令人惊艳的的消费性电子产品世界不断经历快速的变化。传统的单机产品已渐
渐从娱乐设备、家用电器及照明设备中被淘汰。

Click to show

Thick Film Chip Resistors
Thick Film Chip Resistors High Ohmic Value Thick Film Resistors High-Power Thick Film Chip Resistors-HP Ultra High Power Thick Film Chip Resistors - SP High-Voltage Thick Film Chip Resistors - HV High-voltage anti-sulfurized thick film chip resistors-VS Anti-Surge Thick Film Chip Resistors - AS High-Precision Anti-Surge Thick Film Chip Resistors - PS Low T.C.R Thick Film Chip Resistors - LT Flex LED Strip use Thick Film Chip Resistors - LE Wide Terminal Thick Film Chip Resistors - WR Anti-Electro Static Discharge Thick Film Chip Resistors - ES Non-magnetic Thick Film Chip Resistors - NM Complete Pb-Free Thick Film Chip Resistors - PF Automotive Thick Film Chip Resistors - CQ Automotive High Power Thick Film Chip Resistors-HQ Automotive Low Resistance Thick Film Chip Resistors-CS Anti-Sulfurized Automotive Thick Film Chip Resistors - NQ High Quality Anti-Sulfurized Automotive Thick Film Chip Resistors - NS Anti-Sulfurized Thick Film Chip Resistors Array-Convex Terminal Chip Resistors Array Thick Film Chip Resistors Network
Thin Film Chip Resistors
High-Precision Thin Film Chip Resistors - TC High Quality Thin Film Chip Resistors - TA
Alloy Resistors
Metal Foil Chip Resistors - MS Metal Foil Wide Terminal Current Sensing Chip Resistors - MW Metal Strip Chip Resistors-LR Metal Alloy Low Resistance Chip Resistors-ML Metal Film low-resistance Chip Resistors - TL Chip Resistors Shunt - RS
Through Hole Resisitors
Film Resistors Wire-wound Resistors Special type &Forming process Resistors Traditional Cement Resistors Network Resistors
Power Resisitors
Radial Terminal Type Cement Fixed Resistors Terminal Type-With metal mounting bracket Lead Type Cement Fixed Resistors Power Dissipation Mount Fixed Resistors High Power Wire-wound Aluminum Case Resistors Power Alloy Wire-wound Resistors Metal Glaze Film Voltage Divider Resistors
Raw Material
Ceramic Rod Capped Ceramic Rod Carbon Film Capped Ceramic Rod Metal Film Capped Ceramic Rod Metal Oxide Film Capped Ceramic Rod Metal Glaze Capped Ceramic Rod Chemical Nickel - Plating Film Capped Ceramic Rod Zero ohm Copper Plated Rod Zero ohm-Tinned Iron Rod 0Ω Tin-Plated Steel Cap Ceramic Case
Customized inductor
Thermal Fuse Wire-wound Resistors-ASSY Type High Power Wire-wound Flat Aluminum Shell Fixed Resistors-HFWR Type Cement Thermal Fusible Resistors Vertical Type Shrapnel Fuse Resistors - PHF0 Type Array Type Cement Temperature Fusing Resistors - TFRC Type Columnar Type Cement Fixed Resistors-QHO Type Multi-Lead Wire-wound Fixed Resistors - KNHW Type High Power Flat Wire-wound Fixed Resistors - KNHB Type High Power Wire-wound Flat Aluminum Shell Fixed Resistors - HPWR High Power Wire-wound Iron Shell Fixed Resistors - HPWR Type High Power Wire-wound Iron-Case Resistors - HAWF Type High Power Wire-wound Aluminum Shell Resistance - HAWR Type High Power Wire-wound Aluminum Case Resistors High power Starting Resistors

Show 100 Series results

If you need to download the specifications of related products, please click the box in front of your required specifications to be checked, please click the Download PDF button at the top of the form to download the complete specifications .
Download PDF

Series	Product Name	Power	Specifications	Temperature coefficient	Precision	Resistance segment	Specifications	Details
TA	High Quality Thin Film Chip Resistors	3/4W	TA12	±50ppm/℃	±0.5%,±1%	2.49Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	3/4W	TA12	±25ppm/℃	±0.5%,±1%	2.49Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	3/4W	TA12	±50ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	3/4W	TA12	±25ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	3/4W	TA12	±15ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	3/4W	TA12	±10ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/2W	TA10	±50ppm/℃	±0.5%,±1%	2.49Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/2W	TA10	±25ppm/℃	±0.5%,±1%	2.49Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/2W	TA10	±50ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/2W	TA10	±25ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/2W	TA10	±15ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/2W	TA10	±10ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA07	±50ppm/℃	±0.5%,±1%	2.49Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA07	±25ppm/℃	±0.5%,±1%	2.49Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA07	±50ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA07	±25ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA07	±15ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA07	±10ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA06	±50ppm/℃	±0.5%,±1%	2.49Ω≤R≤1.5MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA06	±25ppm/℃	±0.5%,±1%	2.49Ω≤R≤1.5MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA06	±50ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤1.5MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA06	±25ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤1.5MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA06	±15ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/4W	TA06	±10ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/8W	TA05	±50ppm/℃	±0.5%,±1%	2.49Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/8W	TA05	±25ppm/℃	±0.5%,±1%	2.49Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/8W	TA05	±50ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/8W	TA05	±25ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤1MΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/8W	TA05	±15ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤680KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/8W	TA05	±10ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤680KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/10W	TA03	±50ppm/℃	±0.5%,±1%	2.49Ω≤R≤680KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/10W	TA03	±25ppm/℃	±0.5%,±1%	2.49Ω≤R≤680KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/10W	TA03	±50ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤680KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/10W	TA03	±25ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤680KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/10W	TA03	±15ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤332KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/10W	TA03	±10ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤332KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/16W	TA02	±50ppm/℃	±0.5%,±1%	2.49Ω≤R≤220KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/16W	TA02	±25ppm/℃	±0.5%,±1%	2.49Ω≤R≤220KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/16W	TA02	±50ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤220KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/16W	TA02	±25ppm/℃	±0.1% ,±0.25%	4.7Ω≤R≤220KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/16W	TA02	±15ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤68KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/16W	TA02	±10ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	10Ω≤R≤68KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/20W	TA01	±50ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	22Ω≤R≤75KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/20W	TA01	±25ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	22Ω≤R≤75KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/20W	TA01	±15ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	22Ω≤R≤5KΩ	File size:640.69 KB	Details
TA	High Quality Thin Film Chip Resistors	1/20W	TA01	±10ppm/℃	±0.1% ,±0.25% ,±0.5%,±1%	22Ω≤R≤5KΩ	File size:640.69 KB	Details
TC	High-Precision Thin Film Chip Resistors	3/4W	TC12	±50ppm/℃	±0.5%	1Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	3/4W	TC12	±25ppm/℃	±0.5%	1Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	3/4W	TC12	±10ppm/℃	±0.5%	50Ω≤R≤200KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	3/4W	TC12	±5ppm/℃	±0.5%	100Ω≤R≤25KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	3/4W	TC12	±50ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	3/4W	TC12	±25ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	3/4W	TC12	±10ppm/℃	±0.1% 、±0.25%	50Ω≤R≤200KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	3/4W	TC12	±5ppm/℃	±0.1% 、±0.25%	100Ω≤R≤25KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/2W	TC10	±50ppm/℃	±0.5%	1Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/2W	TC10	±25ppm/℃	±0.5%	1Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/3W	TC10	±10ppm/℃	±0.5%	50Ω≤R≤200KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/3W	TC10	±5ppm/℃	±0.5%	100Ω≤R≤25KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/2W	TC10	±50ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/2W	TC10	±25ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/3W	TC10	±10ppm/℃	±0.1% 、±0.25%	50Ω≤R≤200KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/3W	TC10	±5ppm/℃	±0.1% 、±0.25%	100Ω≤R≤25KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/3W	TC07	±50ppm/℃	±0.5%	2.49Ω≤R≤1.5MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/3W	TC07	±25ppm/℃	±0.5%	2.49Ω≤R≤1.5MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/3W	TC07	±10ppm/℃	±0.5%	10Ω≤R≤1MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/3W	TC07	±50ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤1.5MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/3W	TC07	±25ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤1.5MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/3W	TC07	±10ppm/℃	±0.1% 、±0.25%	10Ω≤R≤1MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/4W	TC06	±50ppm/℃	±0.5%	1Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/4W	TC06	±25ppm/℃	±0.5%	1Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/4W	TC06	±10ppm/℃	±0.5%	10Ω≤R≤200KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/4W	TC06	±5ppm/℃	±0.5%	100Ω≤R≤15KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/4W	TC06	±50ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/4W	TC06	±25ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤3MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/4W	TC06	±10ppm/℃	±0.1% 、±0.25%	10Ω≤R≤200KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/4W	TC06	±5ppm/℃	±0.1% 、±0.25%	100Ω≤R≤15KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/8W	TC05	±50ppm/℃	±0.5%	1Ω≤R≤2MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/8W	TC05	±25ppm/℃	±0.5%	1Ω≤R≤2MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/8W	TC05	±10ppm/℃	±0.5%	10Ω≤R≤100KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/8W	TC05	±5ppm/℃	±0.5%	100Ω≤R≤15KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/8W	TC05	±50ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤2MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/8W	TC05	±25ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤2MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/8W	TC05	±10ppm/℃	±0.1% 、±0.25%	10Ω≤R≤100KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/8W	TC05	±5ppm/℃	±0.1% 、±0.25%	100Ω≤R≤15KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/10W	TC03	±50ppm/℃	±0.5%	1Ω≤R≤1MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/10W	TC03	±25ppm/℃	±0.5%	1Ω≤R≤1MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/10W	TC03	±10ppm/℃	±0.5%	10Ω≤R≤50KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/10W	TC03	±5ppm/℃	±0.5%	100Ω≤R≤4KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/10W	TC03	±50ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤1MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/10W	TC03	±25ppm/℃	±0.1% 、±0.25%	4.7Ω≤R≤1MΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/10W	TC03	±10ppm/℃	±0.1% 、±0.25%	10Ω≤R≤50KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/10W	TC03	±5ppm/℃	±0.1% 、±0.25%	100Ω≤R≤4KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/16W	TC02	±50ppm/℃	±0.5%	10Ω≤R≤332KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/16W	TC02	±25ppm/℃	±0.5%	10Ω≤R≤332KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/16W	TC02	±10ppm/℃	±0.5%	50Ω≤R≤12KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/16W	TC02	±5ppm/℃	±0.5%	100Ω≤R≤2KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/16W	TC02	±50ppm/℃	±0.1% 、±0.25%	10Ω≤R≤332KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/16W	TC02	±25ppm/℃	±0.1% 、±0.25%	10Ω≤R≤332KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/16W	TC02	±10ppm/℃	±0.1% 、±0.25%	50Ω≤R≤12KΩ	File size:770.91 KB	Details
TC	High-Precision Thin Film Chip Resistors	1/16W	TC02	±5ppm/℃	±0.1% 、±0.25%	100Ω≤R≤2KΩ	File size:770.91 KB	Details
